Evacuation Plan Drawings in Johor Bahru
Clear, floor-by-floor evacuation plans showing every escape route, exit, assembly point and piece of fire equipment, drawn for each spot they will hang, for factories and premises across Johor Bahru, Pasir Gudang, Senai, Kulai, Iskandar Puteri and Gelang Patah.
A plan people can read in five seconds
In an emergency nobody studies a drawing. They glance at it, find the red dot that says where they are, and follow the nearest route out. An evacuation plan (pelan laluan kecemasan) only works if that glance is enough.
Most plans on factory walls fail that test. They are a photocopied architect's drawing with tiny text, the “you are here” dot is in the wrong place, the plan faces the wrong way, and the exit it points to has been behind racking for two years.
We draw each plan for the exact spot it will hang, turned the way the reader is standing, with only what matters in an emergency. Every plan is drawn to ISO 23601, the international standard for escape and evacuation plan signs, using ISO 7010 safety symbols.
“You are here” for each spot
A separate drawing for every display point, oriented the way the reader faces.
Routes, exits and assembly point
Primary and alternative escape routes, every exit, and where to gather outside.
ISO 23601 & ISO 7010
Drawn to the international standard for evacuation plans, with standard safety symbols for fire extinguishers, hose reels, call points and first aid.
Print-ready files
Delivered ready for your printer or signage supplier, at the size you will display.
Where evacuation plans come in
Safe exit for every workplace
OSHA 1994 section 15 requires every employer to keep safe means of access to and exit from the workplace.
Fire Certificate premises
Designated premises submit a Fire and Emergency Response Plan with their Fire Certificate application and hold a fire drill every year. Clear drawings support both.
ISO and customer audits
ISO 45001 clause 8.2 requires a planned emergency response, and customer auditors look for posted evacuation plans.
Is this you?
- New premiseswith no evacuation plans on the walls yet.
- Factories that changed layoutwith new lines, racking or extensions, so the posted plans no longer match the floor.
- Sites preparing for an auditISO, customer or Fire Certificate, where tidy, correct plans are on the checklist.
- Premises with unreadable plansphotocopied architect drawings that nobody can follow in a hurry.
Drawings, ready to print
One drawing for each display point, each with its own “you are here” marker, escape routes, exits, assembly point, fire equipment and a legend.
Files are print-ready at the size you choose. You print and mount them through your own printer or signage supplier; we do not supply prints, frames or signage.
From your layout to print-ready plans
Send Your Layout
Your floor layout as PDF or CAD, or a clear sketch with photos, plus where each plan will hang.
We Draw
Each plan is drawn for its display point: routes, exits, assembly point and fire equipment.
You Check
Your team walks the routes against the drafts and tells us what to correct.
Final Files
You receive the print-ready files, ready for your printer or signage supplier.
Evacuation plans: common questions
Do we need evacuation plans on our walls?
Every employer must keep safe means of access to and exit from the workplace under OSHA 1994 section 15, and people can only use an exit they know about. Designated premises under the Fire Services Act 1988 must also submit a Fire and Emergency Response Plan with their Fire Certificate application and hold a fire drill at least once a year, and clear evacuation drawings support both. ISO 45001 clause 8.2 requires a planned emergency response, and multinational customers routinely look for posted evacuation plans when they audit suppliers.
Which standard do your drawings follow?
ISO 23601, the international standard for escape and evacuation plan signs. It covers how a displayed plan is laid out: oriented to the reader with a "you are here" marker, a legend, standard safety colours, and the graphical safety symbols of ISO 7010 for exits, fire equipment and first aid. Auditors and multinational customers recognise both standards.
What do you need from us?
Your floor layout, ideally as a PDF or CAD drawing. If you do not have one, a clear sketch with photos of each area, exit and assembly point works. We also need the locations of your fire extinguishers, hose reels, manual call points and first aid points, and where each plan will be displayed.
How many drawings do we need?
One for each display point, not just one per floor. A plan only works if it is drawn the way the reader is standing, with a "you are here" marker for that exact spot, so a plan by the lift lobby and one by the production entrance are different drawings.
Do you print and install the plans?
No. Ours is a drawing service. You receive print-ready files, and you print and mount them through your own printer or signage supplier.
Do you also prepare the Emergency Response Plan or run fire drills?
Our service is the evacuation plan drawings. Your safety officer or Fire Safety Organisation uses them in your Emergency Response Plan, in training and in your annual drill. For emergency response training, see our Safety Training page.
When do the drawings need updating?
Whenever the layout changes: a new production line or racking that alters a route, an exit added or closed, fire equipment moved, or a new assembly point. Out-of-date plans are worse than none, because people trust them.
Applying for or renewing a Fire Certificate? See our BOMBA Fire Certificate service and the Perakuan Bomba guide. For emergency response training, see Safety Training.
Do your plans still match your floor?
Send us your layout and the number of display points. We will reply with a quote.
